Ceramill Matik – More than just a milling machine
Take your fabrication workflows to a new level with the Ceramill Matik. Efficient processes and maximum indication diversity for best-in-class performance and convenience.
Features
Make your daily routines easier with fully automatic cleaning, as well as material and tool management. This effectively optimizes effort and process safety in everyday laboratory routine. Sounds complicated but isn't! Intuitive operation on the integrated machine display supports you in all aspects with guided workflows. With the connection to the AG.Live virtual platform, the Ceramill Matik becomes the core of your CAD/CAM processes. As an intelligent production solution, the Ceramill Matik clearly sets itself apart from conventional milling machines with blank changers.
The Ceramill Matik takes care of cleaning the interior of the milling compartment by itself. Thus, for example, changing from zirconia to metal processing is possible without any manual intervention. This allows you to process orders autonomously, even over the weekend. In addition to automatic cleaning, the Ceramill Matik features a dedicated unit that separates zircon and metal chips from the coolant, thus enabling the workflow and uninterrupted production capability even on weekends. As a result, your cleaning efforts are reduced to regular maintenance.
Stay organized with automated management and avoid interruptions due to worn cutters. With our RFID tracking for the 36 holders, materials, and tools.
Mill the most precise work efficiently with our innovative processing methods such as the patented Carving Mode (60%-time savings), Thrilling (fabrication of one-piece abutments) and Speed Milling of acrylic materials. The Ceramill Matik offers you maximum freedom in the choice of materials, from hard and brittle block materials to zirconia and PMMA, to titanium and cobalt-chromium. Through the continuous expansion of software updates and processing modes, you will always remain up to date.
Perfectly complemented in the workflow with…
Best performance in the digital fabrication process
Focus on the value-creating activities. The Ceramill Matik supports you in everyday laboratory routines with cleaning and the complex management of tools, material and jobs.
Intelligent, clean, efficient
Fully automatic milling machine with intelligent material and tool management. Integrated 36-fold blank tank. 27-fold RFID supported tool tray. Automated cleaning unit. Intuitive operating field with guided workflows.
Automatic cleaning
More focus on the actual work: production.
Integrated materials management
Process reliability thanks to RFID-supported holders.
Intelligent tool management
More efficient workflows thanks to wear indicator.
Full range of materials and indications in an integrated workflow. Discover our validated materials.
Polymers
Ceramic
Technical Data
Compatible with Polymers, Metals, Ceramics, Hybrids and Zirconia
10-axis control for activating the mechanics
27-fold tool management, RFID supported
10” operating display with touchscreen
36-fold blank changer, RFID supported
Industrial zero-point clamping system
Integrated self-cleaning system with chip conveyor and filter
Intelligent management with the AG.Live platform
Dimensions system (DxWxH): 780 x 1265 x 2000mm
HD camera to assist in support cases
High-performance super high frequency spindle (100,000 rpm)
High quality, dynamic and stable 5X system
